Conveyor Type Scissor Platform Lift

Miles 1024 Conveyor Type Scissor Platform Lift the load vertically and allows automatic transfer of the load from one point to another horizontally. Since the transferred product is bulky and heavy, the horizontal movement of the load is provided by conveyors automatically and safely. Having CE certificate, Conveyor Type Scissor Platform Lift is produced in accordance with European machinery directives and offers quality and confidence to the user. Compact and advanced technological design, the Conveyor Type Scissor Platform Lift is fast and easy to install. Miles 1024 Conveyor Type Scissor Platform Lift provides high quality and economical solutions for airports, industrial production facilities and warehouses.

Product Properties

Model

Conveyor Type Scissor Platform Lift - Miles 1024

Technical Specifications

Lifting Capacity (kg): 300-7000

Platform Dimensions (mm): TBD

Pump (L): 10 ~ 240

Motor (kW): 1,5 - 24

Valve Group: BLAIN

Cruising distance (Min/Max) (mm): 0-5000

Motor Supply Voltage (V/AC): 220/380

Pit Dimensions (L x W mm): 2400x4100

Pith Depth (mm): TBD
